Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 399

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 399
MISCELLANEOUS DEVICES. 1629. ACETYLENE GAS GENERATOR, Troubetzkoymodel. Has a water flow governed by the rise in the holder. J, Bal-anced gas holder; G,water seal tank; B, Bjgenerators, two or four;A, small water tank; a^pipe to convey water togenerators; ^, govern-ing valve, operated bythe rise…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
