Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 401

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 401
YLINDER REVOLVINGDEVICE for firearms. a^ the pawl thatcatches the circular ratchet /^; ^, a spring thatpushes the pawl into the teeth of the ratchet;D, the hammer butt to which is pinioned thepawl and the spring E. 1640. MAGAZINE RIFLE, Lee - Metford model.Magazine in the barrel stock.… … 1642. CHASSEPOT GUN.—A needle gun. The cartridgeis inserted by hand; the plunger runs forward and is locked by turn-ing into a notch. Centre fire. MISCELLANEOUS DEVICES. 395 1643. REMINGTON RIFLE.—A breech block, operated by a handle, is pulled back toallow the cartridge to becharged by hand, when…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
