16490. RAILWAYWATER LIFT. — Along water trough be-tween the tracks. Amovable spout in the ten-der is dropped into thewater trough at an angle … to scoop up the water and propel it intothe tank by the speed of the train. 1649&. TWO SPEED GEAR. —TheSunbeam Two Speed mechanism is lo-cated inside the crank chain wheel. Itconsists of one central pinion wheel, andthree small outer pinion wheels which gearinto an internal cut ring. The change…
