Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 71

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 71
SHAKING GRATE for a boiler furnace.— Theflanges are strung uponsquare bars to form eachgrate section, which areshaken or dumped by akey wrench at the front. 64 STEAM POWER. … 205. FURNACE GRATE,with dumping sections. Tup-per model grate.
