Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 76

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 76
227. COMPOUND OSCILLATINGENGINE.—Cylinders at right angles. … 228. TWIN-SCREW OSCILLAT-ING ENGINE.—A through piston rodconnects directly to crank-pins on theshaft face plates. Suitable for smallboats. 229. OSCILLATING HOIST-ING ENGINE.—The piston rodsare attached to an eccentric strap;one fixed, the other pivoted. A leveroperated by the same eccentric…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
