Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 77

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 77
ccentric strap,through a short connecting rod, oper-ates the valve gear of each cylinderalternately. 230. THREE-CYLINDER ENGINE, Brotherhood type. Steam is admitted tothe central chamber with equal pressure onall the pistons. The rotary-disc valve is oper-ated by the crank-pin, giving steam to-the… … 232. TANDEM COMPOUND VERTICALENGINE, with cross-head and two piston rodsfor low-pressure piston ^ .-J U.J ^ v {ri\fl r1( ■i.y 233. COMPOUND ENGINES for twin screws.There may be one or two pair of compound cyUn-ders. The dotted lines represent cylinders of thetandem model.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
