Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 90

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 90
295. COMPENSATING GOVERNOR, *Daw-son patent (English). Intended to be isochronousin its movement. The central weight is connecteddirectly with the throttle-valve stem. … 296. GRAVITY CENTRIFUGAL GOVERNOR.— The weight on the central rod is lifted by the centrifugalaction of the light balls and moves the lever that controlsthe valve gear. A high-speed governor.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
