Mechanics and heat; a text book for collleges and technical schools (1916)
Franklin, William S. (William Suddards), 1863-1930, Macnutt, Barry, 1878-1936, [from old catalog] joint author · New York, The Macmillan company; London, Macmillan & co., ltd. · leaf 261
smade to approach the center may be explained with the help ofFig. 129a as follows: A ball B is twirled on a string 5 which passes B r B f {6 front view side view Fig. 129a. through a tube TT, and after the ball is set in motion the stringis pulled by taking hold of it at P, thus causing the ball… … Fig. 129&. Figure 1296 represents a whirlpool of water in a deep circularbowl. In this case the values of the hydrostatic pressure atthe points a, b and c are proportional to the lengths of the re-spective dotted lines, that is to say, thehydrostatic pressure decreases towardsthe axis of the…
Mechanics · Heat
