Mechanics of engineering. Comprising statics and dynamics of solids: and the mechanics of the materials of constructions, or strength and elasticity of beams, columns, arches, shafts, etc (1888)
Church, Irving P[orter], 1851- [from old catalog] · New York, J. Wiley & sons · leaf 402
ed mechanically by experimenting with alight cord, Fig. 333, to which are hung other heavy cords,or bars of uniform weight per unit length, and at equalhorizontal distances apart when in equilibrium. By varyingthe lengths of the bars, and their points of attachment, wemay finally find the curve… … Fig. 334 necting joints, each piece exerting a thrust T against theadjacent joint. The joint A, (the pin of the hinge), im-agined separated from the contiguous rods and hence free,is held in equilibrium by the vertical force P (a load) andthe two thrusts T and T, making angles = 0 and Q withthe…
Mechanics, Applied · Engineering · Strength of materials
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
