Mechanics of engineering. Comprising statics and dynamics of solids: and the mechanics of the materials of constructions, or strength and elasticity of beams, columns, arches, shafts, etc (1888)
Church, Irving P[orter], 1851- [from old catalog] · New York, J. Wiley & sons · leaf 460
(withinelastic limit, and deformation slight) we must have B J (Mds-t-EI) = zero, since f=0. 372. Projections of the Displacement of any Point of a LoadedRib Relatively to Another Point and the Tangent Line at the Lat-ter.—(There must be no hinge between 0 and B). Let 0be the point whose… … Fig. 410. Fig. 411. Fig. 412. With 0 as an origin and OB as the axis of X, the projec-tion of the displacement OOn upon X, will be called Ax,that upon Y, Ay. In the case in Fig. 410, Os displacement with respect toB and its tangent-line BT, is also its absolute displacementin space, since neither B…
Mechanics, Applied · Engineering · Strength of materials
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
