Mechanics of engineering. Comprising statics and dynamics of solids: and the mechanics of the materials of constructions, or strength and elasticity of beams, columns, arches, shafts, etc (1888)
Church, Irving P[orter], 1851- [from old catalog] · New York, J. Wiley & sons · leaf 475
Fig. 42. … ARCH RIBS. 463 eight equal ^ss and draw a vertical through the middleof each. Let the loads borne by the respective Jss beFlt P2, etc., and with them form a vertical load-line A C tosome convenient scale. With any convenient pole 0draw a trial force diagram 0 AC, and a correspondingtrial…
