Mechanics of the household; a course of study devoted to domestic machinery and household mechanical appliances (1918)
Keene, E. S. (Edward Spencer), b. 1864 · New York, McGraw-Hill book company, inc.; · leaf 111
Fig. 88.—Double Fuller cock for bath tubs. rubber washer that is clamped tight to the surfaces by the nutJS. In case of leakage, the overflow may be removed for repairby unscrewing the union attached to the piece D and removingthe nut B. … Fig. 89. Fig. 89a. Fig. 89.—Overflow attachment for bath tubs, lavatories, etc.Fig. 89a.—Drain attachment for bath tubs, avatories, etc., showing lock-nut and union connection. The drain-pipe connection is shown in Fig. 89a. The plug Dand the flange A show inside the tub. The flange is…
Heating · Lighting · Plumbing
