madeof vitrified tile, laid so as to grade into the street sewer with thegreatest possible pitch. The sections are laid as true as condi-tions will permit and the joints are all carefully filled with cementmortar to prevent leakage. The object of the trap G is to preventsewer gas from entering the… … Next inside the trap is the vent pipe E, that extends to thesurface of the ground. In this case it is just outside the base- 84 MECHANICS OF THE HOUSEHOLD ment wall. The top is covered with a metal cap. Anotherarrangement often made to accomplish the same purpose isshown in Figs. 61 and 62, where a…
