s a pencil,) move thetriangle along the pins as guides ; and the tracer willdescribe the arc required. 11. Or otherwise. Draw the chord A C B; also draw the line H DI, parallel with thechord, and equal tothe height of thesegment; bisect thechord in C, anderect the perpen-dicular C D ; join A D, D B… … number of equal parts; draw the lines 1 1, 2 2, 3 3,&c.; likewise divide the lines A n, B n, each into halfthe number of equal parts ; draw lines to D from eachdivision in the lines An,B n, and, through where theyintersect the former lines, describe a curve, which willbe the arc or segment…
