The mechanic's text-book and engineer's practical guide; containing a concise treatise on the nature and application of mechanical forces; action of gravity; the elements of machinery; rules and tables for calculating the working effects of machinery; of the strength, resistance, and pressure of materials; with tables of the weight and cohesive strength of iron and other metals (1866)
24. To construct a square upon a given right line. From A and B as centres,with the radius A B, describethe arcs A c b, B c d, and fromc, with an equal radius, describethe circle or portion of a circlee d, A B, b c; from b d cut thecircle at e and. c ,k draw thelines A e, B c, also the line…
Mechanical engineering
