Technical mechanics, statics and dynamics (1917)
Maurer, Edward R. (Edward Rose), b. 1869 · New York : John Wiley & sons, inc.; [etc., etc.] · leaf 40
that is, ABC of * The vector of a given couple is perpendicular to the plane of the couple (exact posi-tion of vector immaterial); its length is equal to the moment of the couple accordingto some scale understood; and its sense agrees with the sense (rotation) of the coupleaccording to some rule of… … Fig. 40 3© Chap, i Fig. 41 is ABC of Fig. 40 in true proportions. Then AM (perpendicular toAB), AN (perpendicular to AC), and AO (perpendicular to BC) are respec-tively the vectors of the two given couples and their resultant, provided thatthe lengths of the vectors are proportional to the moments…Mechanics
