ing beam caliper made by the SyracuseTwist Drill Company in the act of gaging a rock drill slide valve,Fig. 70 showing the instrument as it actually appears and Fig.71 with a protecting cover removed in order to show the con-struction. The stationary head of the instrument carries amultiplying… … Fig. 70.—With cover plate in position.
