Methods of machine shop work : for apprentices and students in technical and trade schools (1914)
Halsey, Frederick A. (Frederick Arthur), 1856-1935 · New York : McGraw-Hill · leaf 194
Fig. 162.—Examples of work for which the Fay lathe is adapted. tools of the Fay lathe are controlled by cams, a cam drum,carrying cams upon both its interior and exterior surfaces,being located at the head-stock end of the machine. The turn- … FiG. 163.—Lo-swing lathe. ing-tool carriage is mounted upon a sliding bar which is drawnendwise for the feed by a cam on the interior of the drum. 184 MKTHODS OF MACHINE SHOr WORK The rear of the tool carriage rests upon a support which maybe inclined to the horizontal or be curved if desired and…
Machine-shop practice
