Fig. 102. Fig. 103. Fig. 104. Fig. 102. Abbe Camera Lucida with themirror at 45°, the drawing surface hori-zontal, and the microscope vertical. Axis, Axis. Axial ray from the mi-croscope and from the drawing surface.A B. Marginal rays of the field on thedrawing surface, a b. Sectional view ofthe…
