E APERTURE OF OBJECTIVES.§ 353. Determination of the Aperture of Objectives with an Apertometer.—Ex-cellent directions for using the Abbe apertometer maybe found in the Jour. Roy.Micr. Soc, 1878, p. 19, and 1880, p. 20; in Dippel, Zimmerman and Czapski. Thefollowing directions are but slightly… … Fig. 165. Abbe Apertometer.it consists of a semi-circular plate of glass. Along the straight edge or chord theglass is beveled at 450, and near this straight edge is a small, perforated circle, theperforation being in the center of the circle. To use the apertometer the micro-scope is placed in a…
