l stage as constructed by Leitz. It is shown inposition 011 the stage of the microscope : it is fastened to the stage by a pin and screwnear the pillar. Fig. 69. The Tolles Mayall mechanical stage made by the Bausch & Lomb OpticalCompany. It is separated from the microscope. It is attached to… … llgjgj^^* * Fig. 70. Zeiss Microscope /a with Mechanical Stage. This figure, from ZeissCatalog No. jo, represents the Continental Model of Microscope in its most per-fect form. K. Milled head of the screw for the lateral movements of the stage. L. Screw for fixing the laterally moving mechanism of…
