Military aeroplanes, simplified, enlarged; an explanatory consideration of their characteristics, performances, construction, maintenance, and operation, specifically arranged for the use of aviators and students (1918)
Loening, Grover Cleveland, 1888- · [Boston, W. S. Best printing company] · leaf 30
Courtesy C. G. Grey, Editor The Aeroplane Above : Two views of the Sopwith Camel, a single seater scout,armed with machine guns. Below : Views of the S. E. 5, a British single seater with very highperformances. 15 … The Sopwith tractor biplane—a very widely used type. The side view at the top shows, right toleft, the motor and propeller at the front, the machine gun shooting thru the propeller, the wings, and.at the end of the body, the control surfaces; the rudder is the vertical one, the elevator the…
Airplanes · Aeronautics, Military
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
