Military aeroplanes, simplified, enlarged; an explanatory consideration of their characteristics, performances, construction, maintenance, and operation, specifically arranged for the use of aviators and students (1918)
Loening, Grover Cleveland, 1888- · [Boston, W. S. Best printing company] · leaf 31
The Sopwith tractor biplane—a very widely used type. The side view at the top shows, right toleft, the motor and propeller at the front, the machine gun shooting thru the propeller, the wings, and.at the end of the body, the control surfaces; the rudder is the vertical one, the elevator the… … OLD PUSHER BIPLANES Above—Left—Wilbur Wright, the inventor, and the early type of Wright double pusherbiplane, with elevator out in front. Right—Double screw pusher Wright biplane,of later pattern, elevator in rear. Center — Twin screw, pusher fuselage biplane, with engine in front. Bottom — Left —…
Airplanes · Aeronautics, Military
