The model architect : a series of original designs for cottages, villas, suburban residences, etc., accompanied by explanations, specifications, estimates, and elaborate details : prepared expressly for the use of projectors and artisans throughout the United States (1852)

Sloan, Samuel, 1815-1884 · Philadelphia : E.S. Jones & Co. · leaf 236

An illustration from The model architect : a series of original designs for cottages, villas, suburban residences, etc., accompanied by explanations, specifications, estimates, and elaborate details : prepared expressly for the use of projectors and artisans throughout the United States, 1852, leaf 236
XCTV. is of Details. Fig. 1. Drip ornament of the gable eaves. Fig. 2. Oriel window. Fig. 3. Section of the same.Fig. 4. Hood mould of the front arable first-story window. Fig. 5. Details of the verandah. Fig. 6. Section of the verandah. SUMMER HOUSES.DESIGN TWENTY-THIRD. On plate XCV. will be…

Architecture, Domestic · Country homes

Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
