The model architect : a series of original designs for cottages, villas, suburban residences, etc., accompanied by explanations, specifications, estimates, and elaborate details : prepared expressly for the use of projectors and artisans throughout the United States (1852)

Sloan, Samuel, 1815-1884 · Philadelphia : E.S. Jones & Co. · leaf 82

An illustration from The model architect : a series of original designs for cottages, villas, suburban residences, etc., accompanied by explanations, specifications, estimates, and elaborate details : prepared expressly for the use of projectors and artisans throughout the United States, 1852, leaf 82
coats. This tin is drawn over slats laid from the apex of the roofto the eaves, two feet between centres, as exhibited on the elevation. There are four three inch conductors necessary toconvey the water from the roof. All the materials used in the above work are of the very best quality, and in all… … Design 17/1. Pl.XXXI. 2 e

Architecture, Domestic · Country homes
