Model engine construction, with practical instructions to artificers and amateurs (1894)
Alexander, John Henry. [from old catalog] · London, New York, Whittaker · leaf 326
Fig. 58.—Patterns for making a cylinder. separate pattern for the steam-chest, cast it quitedistinct from the cylinder, and bolt it on after-wards. For the body of the cylinder, take a pieceof hard wood (chuck it between the lathe centres),sufficiently long to include the body A and the 304 MODEL…
Steam-engines · Machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
