sleeve and the crankshaft. A small steel pin is thendriven in this hole, which holds the fly^vheel in place, aswell as the spur gear. The valve will now be explained, together with thesteam chest. The steam chest is formed by a small boxcut out from solid steel and provided with a cover plateof… … 254 Model Engineering screws, as clearly shoAvn in the drawing of the engine.The amount of the projection should not be made toogreat, otherwise the cover plate will have a tendency tobuckle up in the center when the machine screws aretightened. A hole is drilled in each end of the streamchest, one…
