Model making; including workshop practice, design and construction of models, a practical treatise for the amateur and professional mechanic .. (1919)

Yates, Raymond F. (Raymond Francis), 1895- ed · New York, The Norman W. Henley Pub. Co. · leaf 271

An illustration from Model making; including workshop practice, design and construction of models, a practical treatise for the amateur and professional mechanic .., 1919, leaf 271 — 268 Model Engineering bow, and another about, or, better still, a trifle behindcenter. The bow piece and stern piece should next bemade of good clean pieces of oak, free from knots. After … Fig. 179—The Tsoat with the deck removed. The hand water pump isshown at the right this preliminary work has been done, the bow piece moldsand stern piece can be mounted and nailed on a boardas shown in Fig. 180. The following is needed: About 12 feet of %6-inchmahogany 9 inches wide, some odd…
