to bear upon the crankpin at the largeend. A brass strap passes under the crankpin, holding 342 Model Engineering the latter to the connecting rod bearing. This method isperfectly satisfactory, as all of the work done by theconnecting rod is on the down stroke. The strap servesmerely as a means of… … coppceca5z Tig. 277—Showing how a standard market spark plug is reconstructedfor use with the gasolene engine the builder has the patience. The built-up crankshaft isperhaps the easiest if it is well and properly made. The carburetor is a simple mixing valve in whicheither gas or gasolene may be…
