ofthe motor shaft, angularly placed connecting rods lead toa crank mounted on a jackshaft, Avhich in turn is coupledto the drivers by side rods of the type employed on steammachines. This construction, unusual in electric locomo-tives, makes the model a very attractive one. The model,which exhibits… … Fig. 280—The locomotive chassis, showing the driving motors and themethod of gearing them to the drivers every particular. The main frames are cast of brass orbronze, in one piece ^ith the axle boxes, jackshaft bear-ings, and bearing blocks for the shaft corresponding tothe armature of the driving…
