-shaped hmge. The spring is held at the rear endby a bracket bolted to the main frame and the forwardend by a hanger connected to an equalizing lever an-chored to the main frame by pin. The forward truck isthe ordinary equalizing lever type, which needs no fur-ther explanation. The wheels are all… … S54f Model Engineering was used Avhich proved very successful. The wheels werefirst taken in hand, bolted to the face plate, rough turned,centered and drilled % ii^ch for axle. The axles wereturned between centers out of large enough material toprovide for turning all over to % inch diameter.…
