Model making; including workshop practice, design and construction of models, a practical treatise for the amateur and professional mechanic .. (1919)
Yates, Raymond F. (Raymond Francis), 1895- ed · New York, The Norman W. Henley Pub. Co. · leaf 373
Fig. 298—Wiring diagram of the motors and controlling rheostats be daubed A^dth various colored paints to representcamouflage. Being that the driving motors of the tank obtain theirpower from the lighting circuit, it will be necessary tohave the tank pull its feed cables \\dth it. An arrange-ment… … Fig. 299—Drawing showing how the tank appears when completely-assembled structed reel. This reel is provided mth four copperrings and brushes so that the current can pass into thecables while the reel is revolving. Mounted on the boardwith the reel are two small rheostats, one for each motor.By…
