r more dogs, we have a considerable part of ourpreparatory rigging. The tool or tools are held by thebar, a slot cut through the latter providing a means forholding the shank of the cutting tool. The tool is rotated,but is not, in the method set forth, fed to the work eitherparallel with the axis… … Tig. 23—How a boring bar is employed to bore out a steam engine cylinder longitudinal and transverse feed is accomplished by car-rying the work along the lathe axis and shifting it trans-versely. The work is secured, very firmly, to the carriageor rather to the lower portion of the compound rest.…
