The modern builder's assistant, or, A concise epitome of the whole system of architecture : in which the various branches of that excellent study are establish'd on the most familiar principles and rendered adequate to every capacity ... (1757)

Halfpenny, William, d. 1755, Halfpenny, John, 18th cent, Morris, Robert, 1701-1754, Lightoler, T. (Timothy), 18th cent · London : Printed for James Rivington and J. Fletcher ... and Robert Sayer ... · leaf 188

An illustration from The modern builder's assistant, or, A concise epitome of the whole system of architecture : in which the various branches of that excellent study are establish'd on the most familiar principles and rendered adequate to every capacity ..., 1757, leaf 188 — the principal Rafters, andthe fmall Rafters as P K whofe Scantlings are 4 Inches by 3) arehalved on the Back of the Purline, the Curve C E O E C is aaElips, N is the Center of E O E, one third of C E, and D of C B,C C is divided into four Parts, and C E j, C E 3, and NEE are equi-lateral Triangles.…

Architecture · Decoration and ornament

Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
