Modern cabinet work, furniture & fitments; an account of the theory & practice in the production of all kinds of cabinet work & furniture with chapters on the growth and progress of design and construction; illustrated by over 1000 practical workshop drawings, photographs & original designs (1922)
Wells, Percy A, Hooper, John, b. 1882 · Philadelphia, J.B. Lippincott Company · leaf 124
stuff, gauge lines from face sides only, f in. and 2\ in. respec- 3. Templates forDowelling Rails. … 4. Marking Dovetails from Pins. tively from the edge, and where they intersect is the centrefor boring holes. Glue the dowels into one piece,cut to length, and round off ends with dowelrounder, f. 2. A V-shaped groove cut alongdowel with chisel, allows glue and air to escape,and prevents the joint…
Cabinetwork · Furniture making
