Modern cabinet work, furniture & fitments; an account of the theory & practice in the production of all kinds of cabinet work & furniture with chapters on the growth and progress of design and construction; illustrated by over 1000 practical workshop drawings, photographs & original designs (1922)
Wells, Percy A, Hooper, John, b. 1882 · Philadelphia, J.B. Lippincott Company · leaf 52
Section of Bar and Headof a Trammel. Side View off. 2, p. 28. DRAWING—GEOMETRY—PERSPECTIVE, ETC. 29 … 1. Method of Striking an Ellipse with a Straightedge. number of parts as sides in the polygon, say five, and with A and B as centres, and radius A B, describe arcs meeting in C. From C, and through the second division, draw a line cutting the circle at D. The line A D is one side of the pentagon.…
Cabinetwork · Furniture making
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
