Modern cabinetwork, furniture & fitments; an account of the theory & practice in the production of all kinds of cabinetwork & furniture, with chapters on the growth and progress of design and construction; (1910)

Wells, Percy A, Hooper, John · London, B.T. Batsford; New York, Jone Lane company · leaf 142

An illustration from Modern cabinetwork, furniture & fitments; an account of the theory & practice in the production of all kinds of cabinetwork & furniture, with chapters on the growth and progress of design and construction;, 1910, leaf 142
he thickness of rim, projection of top, andfixing or connection of legs to the frame. Ifthis board is shaped to the top line, a templateis thus formed, from the edge of which all linesindicating projections or thicknesses will beparallel. Supposing the rim to be 2 J in. wide,four layers are… … Preparing Curved Templates. layer, thus overlapping each piece, so that eachalternate layer has similar segments. To Prepare the Segments, mark out onboard the joints of one layer in full lines, the nextin dotted pencil lines. Roughly shape a piece of\-m. whitewood to outside line, and pin to…

Cabinetwork · Furniture
