Modern cabinetwork, furniture & fitments; an account of the theory & practice in the production of all kinds of cabinetwork & furniture, with chapters on the growth and progress of design and construction; (1910)
Wells, Percy A, Hooper, John · London, B.T. Batsford; New York, Jone Lane company · leaf 28
sideview of an ordinary jack plane. Thenames of its parts are as follows :—A, toat or handle; B, body or stock ;C, toe ; D, nose ; E, heel; F, escape-ment ; G, mouth, on one side nearlyvertical, on the other at 45 deg.;H, wedge ; I, cutting iron ; J, cap orback iron; K, sole; L, screw. Thesenames… … 2. End of Plane, withRays in RightDirection. 3. End of Plane, show-ing Rays in WrongDirection. MODERN CABINETWORK, FURNITURE, AND FITMENTS. English wooden planes are made of beech, which should always be wellseasoned and straight grained. It should also be cut so that the sole is asnear as possible…
Cabinetwork · Furniture
