Modern cabinetwork, furniture & fitments; an account of the theory & practice in the production of all kinds of cabinetwork & furniture, with chapters on the growth and progress of design and construction; (1910)
Wells, Percy A, Hooper, John · London, B.T. Batsford; New York, Jone Lane company · leaf 320
2. View showing a Rib Chamfered downto Outline. PRACTICAL SETTING OUT AND APPLIED GEOMETRY. 247 … 1. Marking out the Rib Shapes-ist Stage. with a trammel. The figure cl cl dl will now represent a half elevation of thedome, diagram G. The dotted line indicates the outside line of the template,and the inside line is gauged from this edge after it is cut. The segment isobtained in a like manner.…
Cabinetwork · Furniture
