Fig. 40. The soft moulds for the head linings are obtained insimilar manner to those for the head mould, the widthbeing gauged from the head itself PRACTICAL SOLUTIONS 175 A Frame Splayed Lining with Circular Soffit as shown in part elevation in Pig. 39, plan Fig. 40, andsection Fig. 41. The soffit… … Pig. 41. in two pieces joined at the crown and springings. Therails are worked with parallel edges, their centre linesradiating from the centre of the elevation. Edge 1,76 MODERN CARPENTRY moulds only are required for the stiles, and a- developedinould for the panels. The method of obtaining…
