Fig. 48. … Fig. 49. Fig. 50. MECHANICS OF CARPENTRY 341 in C M acting upon joint (3) must be as determined bythe diagram for joint (2). Fig. 44 is the stress dia-gram ; c d is drawn parallel and equal to CD; cmparallel and equal to C M; m 1 and d 1 are drawn paral-lel to M L and L D respectively until they…
