strike train at the right. The positions of arbors,levers, depthings of trains, etc., are exact, but the m.ove-ment plates have been left off for greater clearness, so thatthe arbors appear to be without support. The positions ofthe pillars are shown by the shaded circles above and belowthe trains… … Fig. 101. Front View of Quail and Cuckoo Strike Movement. THE MODEJiX CLOCK. NAMES OF PARTS. 3- A—Quail count wheel. O—Quail Lifting pin wheel. B—Quail striking cam. P—Cuckoo lifting lever. C—r^liuute wheel. Q—Cuckoo warning lever. D—Quail lifting lever. R—Cuckoo lifting pin. E—Quail count hook.…
