ng the following points: In the quailtrain, when the quail bellows lever, H, is just released froma pin in the pin wdieel, O, the locking lever, F, must justfall into the slot of the locking cam, B; the warning pinshould then be near the fly pinion and the count hook, K,drop freely into the count… … Fig. 102. Rear View of Quail and Cuckoo Movement. THE MODERN CLOCK. 3-5 from a pin in the pin wheel, the cuckoo locking lever, S.must drop into its locking cam, U, and the count hook, T,drop into its count wheel, while the warning pin must benear the fly pinion. After the run has stopped and…
