rack; oneside of this pin stops the tail of the quarter gathering palletand therefore locks the train as fully described in Fig. 104.The other side of the same pin acts on the tail of the hourwarning lever, so that whenever the quarter rack falls thehour warning lever is released and its spring… … Fig. 107. Quarter chiming snail strike, Englisli fusee movement. 342 THE MODERN CLOCK. raise the quarter lifting piece, which raises the quarterrack hook and the quarter warning lever at the same time,thus warning and dropping the quarter rack; as soon asthe lifting piece drops, the warning lever…
Clocks and watches
