rious views as the inner plate is turned aboutto show the reverse side, thus reversing the position of rightto left in one view of the inner plate. 360 THE MODERN CLOCK. Fig. 117 shows the wheel for the phases of the moon,which is mounted on the outside of the inner plate imme-diately behind the… … Fig. 116. Dial of Brocots Calendar. The position of this plate is also shown in Fig. 120. Bythe dotted circles, about the center D. The inner side containing the mechanism for indicatingthe days of the week and the days of the month is shown inFig. 118. The calendar is actuated by means of a pin,…
