Modern electrical construction; a reliable, practical guide for the beginner in electrical construction, showing the latest approved methods of installing work of all kinds according to the safety rules of the National board of fire underwriters (1905)

Horstmann, Henry C[harles], 1858- [from old catalog], Tousley, Victor Hugo, 1875- [from old catalog] joint author · Chicago, F. J. Drake & Co. · leaf 123

An illustration from Modern electrical construction; a reliable, practical guide for the beginner in electrical construction, showing the latest approved methods of installing work of all kinds according to the safety rules of the National board of fire underwriters, 1905, leaf 123 — educed to the much smaller lossesin the mains between the upper floors or those farthest fromthe dynamo. Figure 63 shows the method of fusing main switch andbranch circuits. The switch itself will require a fuse to pro-tect it although it need not be right at the switch. It often becomes necessary… … Tf F

Electrical engineering

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
