The modern gas tractor, its construction, utility, operation and repair: a practical treatise defining every branch of up-to-date gas tractor engineering, driving and maintenance in a non-technical manner. Considers fully all types of power plants and their components, methods of drive and speed changing mechanisms. Describes design and construction as well as practical application of tractors in the field (1919)
Pagé, Victor Wilfred, 1885-1947 · New York : Scientific American Pub. Co. · leaf 291
arthest away from the supports. Tractorframes are sometimes built up of two main castings, oneat the front, the other at the rear, joined by channels orsteel angles. The front casting serves as a point ofattachment for the front axle, while the rear member isoften employed to support the important… … The Modern Gas Tractor 285 the frame proper is composed of steel channels, which arefirmly attached together by bolts. A sub-frame is car-ried beneath the main frame and forms a support for thepower plant. The important parts of the transmissionmechanism are clearly shown as is the general…
Farm engines · Internal combustion engines
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
