Axis fob Mqmgmts Fig. 14. Having not passing through the centre of gravity is very easily made,obtained a series of values of the stability arm for a given displacementand condition of loading, they are plotted on a base of angle of inclination.A typical stability curve is indicated in fig. 15.… … InclimaTion in DeGRees.Fig. 15. It will be seen on reference to fig. 14 that with the Amsler integrator itis necessary to trace round each cross-section up to YVL 1, and take the INSTRUMENTS OF CALCULATION 215 readings ; then trace round the portion between WL 1 and 2, take the read-ings, and add…
