Figure 177The Hancock Boiler Washerdelivery water by regulating the steam and water sup-plies with either the starting or water valve or both. STEAM GAUGES The theory and action of the Bourdon spring gaugehas already been discussed to some extent, and willnot be enlarged upon except to give some… … 3^8 LOCOMOTIVE ENGINEERING Crosby Improved Locomotive Pressure Gauge. Attention is called to the cut, Fig. 178, of the Crosby improvedlocomotive pressure gauge, showing the Bourdontube springs and their mechanism. It will be observedthat the tube springs are attached to the socket and tothe tips,…
