ean,strained oil through fillingplug A, and immediatelyafter filling, open watervalve D. Open steam valve(not shown), wait untilsight-feed chambers are filledwith water, then start and regulate the feed by open-ing regulating valves C, more or less, according to thefeed desired. To stop either of… … Figure 195The Kunkle Pop Valve FOR locomotive BOILERS 4O0 LOCOMOTIVE ENGINEERING diately after filling, whether the feed is started again, or not. To oil by hand,close the steamvalve. Fill thehand oilers O,open the hand oiler valves, andwhen all the oilhas entered thetallow pipes, closehand oiler…
